Waveguide Attenuator

Zysen offer Waveguide Fixed Attenuator from WR10 to WR650, Power handling cover 0.25 to 100watts. Custom design is available according to your requirement.

P/N	Frequency Range (GHz)	WG Size	Attenuation (dB)	Power (W)	VSWR
650FA-dB-P	1.12-1.70	WR650	3~30	0.25~100	1.25
510FA-dB-P	1.45-2.20	WR510	3~30	0.25~100	1.25
430FA-dB-P	1.70-2.60	WR430	3~30	0.25~100	1.25
340FA-dB-P	2.20-3.30	WR340	3~30	0.25~100	1.25
284FA-dB-P	2.60-3.95	WR284	3~30	0.25~100	1.25
229FA-dB-P	3.30-4.90	WR229	3~30	0.25~100	1.25
187FA-dB-P	3.95-5.85	WR187	3~30	0.25~100	1.25
159FA-dB-P	4.90-7.05	WR159	3~30	0.25~100	1.25
137FA-dB-P	5.85-8.20	WR137	3~30	0.25~100	1.25
112FA-dB-P	7.05-10.0	WR112	3~30	0.25~100	1.25
90FA-dB-P	8.20-12.4	WR90	3~30	0.25~100	1.25
75FA-dB-P	10.0-15.0	WR75	3~30	0.25~100	1.25
62FA-dB-P	12.4-18.0	WR62	3~30	0.25~100	1.25
51FA-dB-P	15.0-22.0	WR51	3~30	0.25~100	1.25
42FA-dB-P	18.0-26.5	WR42	3~30	0.25~100	1.25
34FA-dB-P	22.0-33.0	WR34	3~30	0.25~100	1.25
28FA-dB-P	26.5-40.0	WR28	3~30	0.25~100	1.25
22FA-dB-P	33.0-50.0	WR22	3~30	0.25~10	1.30
19FA-dB-P	40.0-60.0	WR19	3~30	0.25~5	1.30
15FA-dB-P	50.0-75.0	WR15	3~30	0.25~2	1.30
12FA-dB-P	60.0-90.0	WR12	3~30	0.25~2	1.30
10FA-dB-P	75.0-110.0	WR10	3~30	0.25~2	1.30

Ordering Information	WR	Mod	-dB	-P
Example part number:	112	FA	-30	5
	Waveguide Size	Fixed Attenuator	Attenuation: 3~30dB	Power
