P/N |
Pass Band |
I.L. |
Stop Band |
Average Power |
VSWR |
Connector |
Size (mm) |
|
ZSHP-10100-S |
1-10 |
1.5 |
60 @ D5-0.78 |
15 |
1.5 |
SMA-F |
61x23x10 |
|
ZSHP-15130-S |
1.5-13 |
1.2 |
50 @ DC-1.0 |
15 |
1.8 |
SMA-F |
53x20x10 |
|
ZSHP-20190-S |
2-19 |
1.5 |
50 @ DC-1.58 |
15 |
1.5 |
SMA-F |
37x18x10 |
|
ZSHP-30180-S |
3-18 |
1.5 |
65 @ DC-2.0 |
15 |
1.8 |
SMA-F |
31x17x10 |
|
ZSHP-40230-S |
4-23 |
1.5 @ 4.0-4.15G 1.0 @ 4.15-23G |
50 @ DC-3.2 |
15 |
1.8 |
SMA-F |
25x16x10 |
|
ZSHP-50250-S |
5-25 |
1.5 @ 5.0-5.2G 1.0 @ 5.2-25G |
50 @ DC-4.0 |
15 |
1.8 |
SMA-F |
23x16x10 |
|
ZSHP-80280-S |
8-28 |
1.5 @ 8.0-8.3G 1.0 @ 8.3-28G |
50 @ DC-6.65 |
15 |
1.8 |
SMA-F |
19x15x10 |
|
ZSHP-180400-S |
18-40 |
2.0 @ 18-19.5G 1.8 @ 19.5-40G |
50 @ DC-15.0 |
15 |
1.8 |
2.92mm-F |
12.7x12.7x10 |
|
ZSHP-80400-S |
8-40 |
1.2 |
50 @ DC-5.0 |
15 |
2.0 |
2.92mm-F |
30x22x10 |
